Anthos

• Anthos is a multi cloud and hybrid platform.
• Built on the top of Kubernetes, Istio, and Knative.

Core components

Anthos GKE:

• It is a Kubernetes cluster present on the cloud environment and on premises.
• For on prem it is GKE On-Prem (1.0).
• Generally used for  storage and CICD solutions.
• Supports Stackdriver components for monitoring and Logging.
• Following features of Kubernetes are  supported in Anthos GKE.
  • Management of the node pools.
  • Node Auto-repair.
  • Scaling.
  • Automatic upgrades.
  • Support in Alpha and Beta versions.

Anthos Config Management:

• Common configuration point for your hybrid workloads.
• It reads the configuration from Git the git repository.
• Cluster objects are stored in a cluster/ directory.
• Namespace objects are stored in a Namespace/ directory.
• System objects are stored in a system/ directory.
• Sample config for the namespace in the production environment.

  apiVersion: v1
  kind: Namespace
  metadata:
  name: shipping-prod
  labels:
  env: prod
  annotations:
  audit: "true"

Anthos Service Mesh:

• It is an Istio-compatible framework.
• It connects on prem services with the cloud GKE.
• Pre integrated stackdriver.
• Provide an extra layer of security with TLS.

Setting up Anthos:

• Clone the repo.

  git clone https://github.com/GoogleCloudPlatform/anthos-workshop.git anthos-workshop
  cd anthos-workshop
  source ./env
  ./bootstrap-workshop.sh

• Review the cluster in Kubernetes Engine → Clusters in GCP Console.
• Set up the remote cluster.

  kubectx remote

  Assign the gkehub.connect Cloud IAM role to the anthos-connect service account.

  export PROJECT=$(gcloud config get-value project)
  export GKE_CONNECT_SA=$PROJECT
  export GKE_SA_CREDS=$WORK_DIR/$GKE_CONNECT_SA-creds.json

  gcloud projects add-iam-policy-binding $PROJECT \
  --member="serviceAccount:$GKE_CONNECT_SA@$PROJECT.iam.gserviceaccount.com" \
  --role="roles/gkehub.connect"

• Create a private key and download it.

  gcloud iam service-accounts keys create $GKE_SA_CREDS \
  --iam-account=$GKE_CONNECT_SA@$PROJECT.iam.gserviceaccount.com \
  --project=$PROJECT

• Register on prem cluster.

  export REMOTE_CLUSTER_NAME_BASE="remote"
  export REMOTE_CLUSTER_NAME=$REMOTE_CLUSTER_NAME_BASE.k8s.local
  export REMOTE_KUBECONFIG=$WORK_DIR/remote.context

  cloud beta container memberships register $REMOTE_CLUSTER_NAME_BASE \
  --context=$REMOTE_CLUSTER_NAME \
  --service-account-key-file=$GKE_SA_CREDS \
  --kubeconfig=$REMOTE_KUBECONFIG \
  --project=$PROJECT

• Create a service account for the remote cluster and use a token from it to login into the remote cluster.
• Go to Kubernetes Engine > Clusters.
• Click on the Login button of the remote cluster.
• Use the auth method as a Token.
• Paste the Token generated from the service account.
• Now the remote cluster has been set up.

• Register the key using https://source.cloud.google.com/user/ssh_keys
• Click on “Register SSH key ”
• Type your GCP console password.

Apply the Config:

export REMOTE=remote
export CENTRAL=central
REPO_URL=ssh://${GCLOUD_ACCOUNT}@source.developers.google.com:2022/p/${PROJECT}/r/config-repo

kubectx $REMOTE
# Replace variables and stream results to kubectl apply
cat $BASE_DIR/config-management/config_sync.yaml | \
sed 's|<REPO_URL>|'"$REPO_URL"'|g' | \
sed 's|<CLUSTER_NAME>|'"$REMOTE"'|g' | \
sed 's|none|ssh|g' | \
kubectl apply -f -

kubectx $CENTRAL
cat $BASE_DIR/config-management/config_sync.yaml | \
sed 's|<REPO_URL>|'"$REPO_URL"'|g' | \
sed 's|<CLUSTER_NAME>|'"$CENTRAL"'|g' | \
sed 's|none|ssh|g' | \
kubectl apply -f -

Push the Config:

mkdir namespaces/checkout

cat <<EOF > namespaces/checkout/namespace.yaml
apiVersion: v1
kind: Namespace
metadata:
name: checkout
EOF

export EMAIL=$(gcloud config get-value account)
git config --global user.email "$EMAIL"
git config --global user.name "$USER"

git add . && git commit -m 'adding checkout namespace'
git push origin master

Conclusion:

Hybrid or even Multi Cloud will soon be reality for many organizations. A strong hybrid cloud solution is needed to realize the advantages of the public cloud and to keep the (operating) effort and costs within reasonable limits.
